Piston Filling Machine

Products Details

Piston Filling Machine Product Detail: Quick Details: Condition: New    Application: Bottle     Plastic Processed: Blow Mould Type:   Automatic:    Place of Origin: Shanghai China (Mainland) Brand Name: Joysun   Model Number:    USE: Industrial Use: Beverage     Material: Metal    Metal Type: Steel


This is a timed flow volumetric filling machine which is controlled by the piston so that the filling precision is ensured. The bulk supply of piston filling machine is pumped into a holding tank above a set of pneumatically operated valves, each one of which is independently timed by the master computer. Thus, the exact amount of liquid will be forced into the container through gravity. Characteristics 1. In a single filling cycle, this filling machine can achieve the maximum filling volume through several times filling.  2. The interface and PLC control system is user-friendly. 3. A pneumatic valve is designed to prevent bottles from nozzle dripping. 4. Servo nozzle height (Submersible filling is optional) 5. No materials/no fill (suspend operation) 6. No bottle/no fill (suspend operation) 7. Encounter obstruction /no fill (suspend operation) Technical Specifications
Model Filling valve Filling volume (ml) Production capacity (bph) Bottle diameter(mm) Bottle height(mm) Power (kw)
ZG-4 4 20-1000 1000-2500 Ø 20- Ø 150 160-300 3.5
ZG-8 8 20-1000 2500-4000 Ø 20- Ø 150 160-300 3.5
ZG-12 12 20-1000 4000-6000 Ø 20- Ø 150 160-300 3.5

51 55



56 57
